• Year
  • 1980 ??
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 296742

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Wave bands
  • - without
  • Power type and voltage
  • Dry Batteries / 9 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Multimeter TES-2360 - TES Electrical Electronic Corp
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 88 x 187 x 37 mm / 3.5 x 7.4 x 1.5 inch
  • Notes
  • Auto-power off 3-3/4 digital meter


    AC: 750 V; 10 A
    DC: 1000 V; 10 A
    R: 40 MΩ
    Diode and continuity tone
    Hz: 4000 kHz
    Logic
    Capacitance: 400 μF
    Inductance: 40 H
    Transistor hFE: 0-1000 (NPN and PNP)
    Temperature: -40ºC - 150ºC with diode type sensor (TP-D05)
    Peak Hold Measurement: Voltage & current (DC/AC)

  • Net weight (2.2 lb = 1 kg)
  • 0.374 kg / 0 lb 13.2 oz (0.824 lb)
  • Literature/Schematics (1)
  • - - Manufacturers Literature
  • Author
  • Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
