Start ANP402; Tesla; Praha, (ID = 2536006) R-Player
Tesla; Praha,: Start ANP402 [R-Player] ID = 2536006 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model Start ANP402, Tesla; Praha, Bratislava etc.

Country:  Czechoslovakia
Manufacturer / Brand:  Tesla; Praha, Bratislava etc.
Brand

Supraphon
Year: 1962 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 6:
Details Tape Recorder
Power type and voltage Line / Batteries (any type) / 220; (6 × 1,5; 12) Volt
Loudspeaker
Power out
from Radiomuseum.org Model: Start ANP402 - Tesla; Praha, Bratislava etc.
Material Various materials
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 250 x 100 x 160 mm / 9.8 x 3.9 x 6.3 inch
Notes Bandgeschwindigkeit: 4,75 cm/s, 2 Spur, Frequenzgang: 150...6000 Hz; Aussteuerungsanzeige, sehr einfach gebauter Recorder. Bandgeschwindigkeit: 4,75 cm/s, 2 Spur, Spulen: bis zu 8 cm Durchmesser, Frequenzgang: 150...6000 Hz, Aussteuerungsanzeige: keine, Löschen: DC, Permanentmagnet, Löschkopf drehbar, BIAS: HF, cca 55 kHz, Gleichlaufschwankungen: 1 %.
Net weight (2.2 lb = 1 kg) 3.4 kg / 7 lb 7.8 oz (7.489 lb)
Source of data - - Data from my own collection

Model page created by Wolfgang Lill. See "Data change" for further contributors.



All listed radios etc. from Tesla; Praha, Bratislava etc.
Here you find 1798 models, 1095 with images and 553 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Tesla; Praha,: Start ANP402
Threads: 1 | Posts: 1
Hits: 1985     Replies: 0
tesla: ANP402 (ANP 402); Start
Gerd Krause
06.Oct.06
  1 Das Gerät wurde in Deutschland u.a. vom Versandhaus Quelle vertrieben
