Mambo 2816B

Mambo 2816B; Tesla; Praha, (ID = 533588) Radio

Mambo 2816B; Tesla; Praha, (ID = 668415) Radio
Mambo 2816B; Tesla; Praha, (ID = 1220801) Radio Mambo 2816B; Tesla; Praha, (ID = 1916903) Radio
Mambo 2816B; Tesla; Praha, (ID = 1916904) Radio Mambo 2816B; Tesla; Praha, (ID = 1916905) Radio
Mambo 2816B; Tesla; Praha, (ID = 1977503) Radio Mambo 2816B; Tesla; Praha, (ID = 1977504) Radio
Mambo 2816B; Tesla; Praha, (ID = 1977505) Radio Mambo 2816B; Tesla; Praha, (ID = 1977506) Radio
Mambo 2816B; Tesla; Praha, (ID = 1977507) Radio
Use red slider bar for more.
Mambo 2816B; Tesla; Praha, (ID = 1220801) Radio
Tesla; Praha,: Mambo 2816B [Radio] ID = 1220801 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Mambo 2816B, Tesla; Praha, Bratislava etc.:
Foto:Bernhard Heinze. Vielen Dank !

Country:  Czechoslovakia
Manufacturer / Brand:  Tesla; Praha, Bratislava etc.
Brand

Supraphon
Year: 1966–1968 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9:
Main principle Superheterodyne (common); ZF/IF 468/10700 kHz
Tuned circuits 5 AM circuit(s)     8 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Dry Batteries / 2 × 3 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 cm = 2.4 inch
Power out 0.2 W (unknown quality)
from Radiomuseum.org Model: Mambo 2816B - Tesla; Praha, Bratislava etc.
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 185 x 102 x 37 mm / 7.3 x 4 x 1.5 inch
Notes Transistoren: 5× OC170, 2× GC516, 2× SFT352 (Gegentakt-B-Endstufe); OIRT-Band: 73,5-65,2 MHz.
Net weight (2.2 lb = 1 kg) 0.6 kg / 1 lb 5.1 oz (1.322 lb)
Mentioned in Ceskoslovenske Rozhlasove a Televizni Prijimace a Zesilovace

Model page created by Wolfgang Lill. See "Data change" for further contributors.



All listed radios etc. from Tesla; Praha, Bratislava etc.
Here you find 1791 models, 1091 with images and 549 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Tesla; Praha,: Mambo 2816B
Threads: 1 | Posts: 1
Hits: 1698     Replies: 0
tesla: 2816B ; Mambo
Karl - Heinz Bossan
12.May.11
  1

der Kaufpreis betrug laut kassenzettel vom 20.02.1968 320,00 DM
