NC130

NC130; Tesla; Praha, (ID = 717631) R-Player NC130; Tesla; Praha, (ID = 1199488) R-Player
NC130; Tesla; Praha, (ID = 1199490) R-Player NC130; Tesla; Praha, (ID = 1199489) R-Player
NC130; Tesla; Praha, (ID = 163992) R-Player NC130; Tesla; Praha, (ID = 2303102) R-Player
NC130; Tesla; Praha, (ID = 2303101) R-Player
Use red slider bar for more.
NC130; Tesla; Praha, (ID = 717631) R-Player
Tesla; Praha,: NC130 [R-Player] ID = 717631 900x675
Select picture or schematic to display from thumbnails on the right and click for download.
For model NC130, Tesla; Praha, Bratislava etc.:
Fotografiert in einem AV-Geschäft in Tschechien.

Country:  Czechoslovakia
Manufacturer / Brand:  Tesla; Praha, Bratislava etc.
Brand

Supraphon
Year: 1975 ?? Category: Sound/Video Recorder and/or Player
Wave bands - without
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 120/220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: NC130 - Tesla; Praha, Bratislava etc.
Material Various materials
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 395 x 150 x 300 mm / 15.6 x 5.9 x 11.8 inch
Notes Stereoplattenspieler mit 16/33/45 UpM; Kristallabtastsystem Type VK4202; Laufwerk HC13, automatische Endabschaltung und Rückführung des Tonarmes in die Ausgangsstellung. Gehäuse: Holz mit Acrylabdeckhaube.
Net weight (2.2 lb = 1 kg) 4.5 kg / 9 lb 14.6 oz (9.912 lb)
Price in first year of sale 960.00 CZK
Source of data -- Original prospect or advert

Model page created by Wolfgang Lill. See "Data change" for further contributors.
