• Year
  • 1966/1967
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 108437
    • Brand: Supraphon

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 3
  • Main principle
  • Superheterodyne (common); ZF/IF 468 kHz
  • Tuned circuits
  • 6 AM circuit(s)     8 FM circuit(s)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 120/220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Power out
  • 1.5 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Nocturno 324A - Tesla; Praha, Bratislava etc.
  • Shape
  • Tablemodel with Push Buttons.
  • Notes
  • Semiconductor diodes: GA206, rectifier PM28RA. UKW: OIRT-Band 66...73,5 MHz.
  • Source of data
  • -- Collector info (Sammler)
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
