Sweep Frequency Generator BM419

Tesla; Praha, Bratislava etc.

  • Year
  • 1965
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 165653
    • Brand: Supraphon

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 7
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 120/220 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Sweep Frequency Generator BM419 - Tesla; Praha, Bratislava etc.
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 320 x 265 x 225 mm / 12.6 x 10.4 x 8.9 inch
  • Notes
  • Frequency range 15 - 230MHz.
  • Net weight (2.2 lb = 1 kg)
  • 11.5 kg / 25 lb 5.3 oz (25.33 lb)
  • Price in first year of sale
  • 4,300.00 ATS
  • Source of data
  • -- Original-techn. papers.
  • Author
  • Model page created by Gabriel Toth. See "Data change" for further contributors.
