- Country
- Spain
- Manufacturer / Brand
- Thomson Española S.A.; Thomson General Eléctrica; Cedosa; Electa; Setelsa; Madrid
- Year
- 1978 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 325887
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 1
- Valves / Tubes
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superhet with RF-stage; ZF/IF 38900 kHz
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Line / Storage batteries (perhaps also batteries) / 127; 220 / 12 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: 12J4 Ch= S20 - Thomson Española S.A.; Thomson
- Shape
- Tablemodel, low profile (big size).
- Notes
-
Thomson Española S.A., Televisor portable 12J4
TV B/N 12" con sintonizador transistorizado de VHF/UHF Fagor SDF-40
Este modelo es idéntico al 12S4 pero con juegos incorporados.
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
