• Year
  • 1983 ??
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 317297

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Cassette-Recorder or -Player
  • Loudspeaker
  • - For headphones or amp.
  • from Radiomuseum.org
  • Model: Cassette Deck Estereofónico CD-250E - Thomson Española S.A.; Thomson
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 440 x 124 x 270 mm / 17.3 x 4.9 x 10.6 inch
  • Notes
  • Thompson Española S.A. Cassette Deck Estereofónico CD-250E

    Cassette para cinta normal, CrO2 (cromo) y metal.

  • Net weight (2.2 lb = 1 kg)
  • 5 kg / 11 lb 0.2 oz (11.013 lb)
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
