• Year
  • 1986 ??
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 317058

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Cassette Deck Estereofónico CD-306 - Thomson Española S.A.; Thomson
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 430 x 75 x 270 mm / 16.9 x 3 x 10.6 inch
  • Notes
  • Thompson Española S.A. Cassette Deck Estereofónico CD-306

    Cassette para cinta normal, CrO2 (cromo) y metal.

    Véase también Nordmende CD-1351 (la foto que viene en el manual Thomson es la del Nordmende)

  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
