• Year
  • 1986 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 316312

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 1
  • Main principle
  • Superheterodyne (common); ZF/IF 455/10700 kHz
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Batteries / addl. power jack / AA: 4 x 1,5 / 6 Volt
  • Loudspeaker
  • - only for Earphone!
  • Power out
  • 0.04 W (undistorted)
  • from Radiomuseum.org
  • Model: LK-205 - Thomson Española S.A.; Thomson
  • Dimensions (WHD)
  • 150 x 38 x 88 mm / 5.9 x 1.5 x 3.5 inch
  • Notes
  • Thompson Española S.A. Radio Cassette Estéreo LK-205 (RP-45)

    Véase modelo similar Saba RP-45

  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
