S3501 M7 8329

S3501 M7 8329; Thomson marque, (ID = 277107) Radio

S3501 M7 8329; Thomson marque, (ID = 277108) Radio

S3501 M7 8329; Thomson marque, (ID = 277109) Radio

S3501 M7 8329; Thomson marque, (ID = 277110) Radio

S3501 M7 8329; Thomson marque, (ID = 277111) Radio

S3501 M7 8329; Thomson marque, (ID = 277112) Radio

S3501 M7 8329; Thomson marque, (ID = 277114) Radio

S3501 M7 8329; Thomson marque, (ID = 277115) Radio

S3501 M7 8329; Thomson marque, (ID = 277116) Radio

S3501 M7 8329; Thomson marque, (ID = 277117) Radio
S3501 M7 8329; Thomson marque, (ID = 275371) Radio
Use red slider bar for more.
S3501 M7 8329; Thomson marque, (ID = 275371) Radio
Thomson marque,: S3501 M7 8329 [Radio] ID = 275371 933x392
Select picture or schematic to display from thumbnails on the right and click for download.
For model S3501 M7 8329, Thomson (marque), Thomson-Houston (CFTH, Mazda); Paris

Country:  France
Manufacturer / Brand:  Thomson (marque), Thomson-Houston (CFTH, Mazda); Paris
Year: 1977 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 20:
Main principle Superheterodyne (common); ZF/IF 460 kHz
Tuned circuits 6 AM circuit(s)     6 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110/220 Volt
Loudspeaker
Power out
from Radiomuseum.org Model: S3501 M7 8329 - Thomson marque, Thomson-
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 440 x 136 x 290 mm / 17.3 x 5.4 x 11.4 inch
Notes

3 ICs in adition of the 20 transistors

Voir aussi:

  • Thomson Española, S.A. S-3501
  • Thomson (Houston?) T-3004-T
  • Phaté-Marconi T-3004-V
  • Pathé-Marconi T-3051-V
Net weight (2.2 lb = 1 kg) 4.7 kg / 10 lb 5.6 oz (10.352 lb)
Price in first year of sale 12'400.00 ESP
Source of data - - Data from my own collection
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Jose Gonzalez-Varela. See "Data change" for further contributors.
