Double Cassette Play Amplifier BA-823

Toa Electric Co., Ltd. 東亜; Kobe

  • Year
  • 1995 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 262323

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Alternating Current supply (AC) / 230-240 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Power out
  • 60 W (undistorted)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Double Cassette Play Amplifier BA-823 - Toa Electric Co., Ltd. 東亜;
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 420 x 97 x 300 mm / 16.5 x 3.8 x 11.8 inch
  • Notes
  • Distortion Less than 1% (100Hz at rated output on AUX 2 input).
    Frequency Response Tape; 50 ~ 15,000Hz / AUX 2 50 ~ 20,000Hz (± 3dB)
    Tone Control Bass; 100Hz ± 10dB / Treble; 10kHz ± 10dB
    Input Mic; 600 Ω 1mV, balanced / AUX 1; 50k Ω 100mV, unbalanced / AUX 2, 600 Ω, 1V, unbalanced / LINE IN (signal); 10k Ω, 150mV, unbalanced.
    Output SPEAKER OUTPUT; 30W+30W at 8Ohm
    S / N Ratio TAPE; 50dB (Dolby NR, OFF), AGC OFF; 60DB (Dolby NR, ON), AGC OFF / MIC; 60dB.
    Tape Speed 4.76cm / sec.
    Wow and Flutte Less than 0.2% (WRMS).
    Playing System Auto-reverse.



  • Net weight (2.2 lb = 1 kg)
  • 8.5 kg / 18 lb 11.6 oz (18.722 lb)
  • Author
  • Model page created by Bartosz Szwed. See "Data change" for further contributors.
