Impedance Meter ZM-104

Toa Electric Co., Ltd. 東亜; Kobe

  • Year
  • 1977 ??
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 201012

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Wave bands
  • - without
  • Power type and voltage
  • Dry Batteries / 4 x 1,5 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Various materials
  • from Radiomuseum.org
  • Model: Impedance Meter ZM-104 - Toa Electric Co., Ltd. 東亜;
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 115 x 186 x 55 mm / 4.5 x 7.3 x 2.2 inch
  • Notes
  • Impedance Meter (1000 Hz).
  • Net weight (2.2 lb = 1 kg)
  • 0.960 kg / 2 lb 1.8 oz (2.115 lb)
  • Author
  • Model page created by Hugo Sneyers. See "Data change" for further contributors.
