For model Èlektronika - Elektronika - Электроника 302, TochMash Moskow mashine Works

Country:  Soviet Union
Manufacturer / Brand:  TochMash Moskow mashine Works
Year: 1974 ?? Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Line / Batteries (any type) / 220/127, 6 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Èlektronika - Elektronika - Электроника 302 - TochMash Moskow mashine Works
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 315 x 225 x 90 mm / 12.4 x 8.9 x 3.5 inch
Notes Cassette tape recorder, tone control, VU meter.
External AC 220V power supply block.
Net weight (2.2 lb = 1 kg) 3.5 kg / 7 lb 11.3 oz (7.709 lb)

Model page created by a member from A. See "Data change" for further contributors.



All listed radios etc. from TochMash Moskow mashine Works
Here you find 4 models, 3 with images and 1 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
TochMash Moskow: Èlektronika - Elektronika - Электроника 302
Threads: 2 | Posts: 2
Hits: 216     Replies: 0
tochmash: Elektronika 302
Egon Strampe
04.Sep.20
  1


Hits: 1360     Replies: 0
tochmash: 302; Elektronika
Egon Strampe
22.Mar.09
  1

Ergänzung: Die Ergänzung bezieht sich auf ein Überbrücken der Basis-Emitterstrecke des Transistors V5 mit einem Kondensator 3,3nF. Diese Nachrüstung ist speziell bei Störungen im Bereich der Indikatoransteuerung notwendig.

Robotron-Mitteilung aus radio fernsehen elektronik 8/81


TochMash Moskow: Èlektronika - Elektronika - Электроника 302
