Candle 3 Band 12 Transistor FM/SW-AM VM-1210

Candle 3 Band 12 Transistor FM/SW-AM VM-1210; Tokyo Transistor (ID = 2544797) Radio
Candle 3 Band 12 Transistor FM/SW-AM VM-1210; Tokyo Transistor (ID = 1144743) Radio Candle 3 Band 12 Transistor FM/SW-AM VM-1210; Tokyo Transistor (ID = 1144745) Radio
Candle 3 Band 12 Transistor FM/SW-AM VM-1210; Tokyo Transistor (ID = 1144747) Radio Candle 3 Band 12 Transistor FM/SW-AM VM-1210; Tokyo Transistor (ID = 2544594) Radio
Candle 3 Band 12 Transistor FM/SW-AM VM-1210; Tokyo Transistor (ID = 2544595) Radio Candle 3 Band 12 Transistor FM/SW-AM VM-1210; Tokyo Transistor (ID = 2544596) Radio
Candle 3 Band 12 Transistor FM/SW-AM VM-1210; Tokyo Transistor (ID = 2544597) Radio Candle 3 Band 12 Transistor FM/SW-AM VM-1210; Tokyo Transistor (ID = 2544598) Radio
Use red slider bar for more.
Candle 3 Band 12 Transistor FM/SW-AM VM-1210; Tokyo Transistor (ID = 1144743) Radio
Tokyo Transistor: Candle 3 Band 12 Transistor FM/SW-AM VM-1210 [Radio] ID = 1144743 933x633
Select picture or schematic to display from thumbnails on the right and click for download.
For model Candle 3 Band 12 Transistor FM/SW-AM VM-1210, Tokyo Transistor Industry Co., LTD.; Tokyo

Country:  Japan
Manufacturer / Brand:  Tokyo Transistor Industry Co., LTD.; Tokyo
Brand

Candle
Year: 1966 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 12:
Semiconductors (the count is only for transistors) 2SA235 2SA235 2SA235 2SA234 2SA350 2SA350 2SA350 2SB155 2SB75 2SB77 2SB156 2SB156
Main principle ZF/IF 455/10700 kHz; 3 AF stage(s)
Tuned circuits 5 AM circuit(s)     8 FM circuit(s)
Wave bands Broadcast, Short Wave plus FM or UHF.
Details
Power type and voltage Dry Batteries / C: 4 x 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9 cm = 3.5 inch
Power out 0.4 W (0.5 W max.)
from Radiomuseum.org Model: Candle 3 Band 12 Transistor FM/SW-AM VM-1210 - Tokyo Transistor Industry Co.,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 240 x 160 x 60 mm / 9.4 x 6.3 x 2.4 inch
Notes Mittelwelle: 510 - 1620 kHz
Kurzwelle: 4 - 12 MHz
UKW: 86 - 108 MHz.
Net weight (2.2 lb = 1 kg) 1.1 kg / 2 lb 6.8 oz (2.423 lb)
Source of data - - Data from my own collection

Model page created by Karl-Heinz Entrich. See "Data change" for further contributors.
