Wall Radio 7TH-425, 7TH-425Y
Toshiba Corporation; Tokyo
- Country
- Japan
- Manufacturer / Brand
- Toshiba Corporation; Tokyo
- Year
- 1961 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 107853
-
- alternative name: Shibaura Engineering Works
- Brand: Tokyo Shibaura
Advertisement (unknown source)
- Number of Transistors
- 7
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Dry Batteries / D: 4 x 1.5 Volt
- Loudspeaker
- 2 Loudspeakers / Ø 9 cm = 3.5 inch
- Power out
- 0.5 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Wall Radio 7TH-425, 7TH-425Y - Toshiba Corporation; Tokyo
- Shape
- Design Radio or Novelty / Gadget - fancy or unusual shape.
- Dimensions (WHD)
- 11.5 x 11.5 x 0 inch / 292 x 292 x 0 mm
- Notes
-
7 transistor superheterodyne with push-pull power transistor output. Frequency range 540 - 1600 Kc.
Wall mount radio finished in black with gold trim, or white with gold trim.
- Price in first year of sale
- 69.95 $
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Date 10-61 Set 551 Folder 14)
- Author
- Model page created by Peter Hoddow. See "Data change" for further contributors.
