AM Radio RP-82

AM Radio RP-82; Toshiba Corporation; (ID = 1624464) Radio AM Radio RP-82; Toshiba Corporation; (ID = 1624465) Radio
AM Radio RP-82; Toshiba Corporation; (ID = 1624466) Radio AM Radio RP-82; Toshiba Corporation; (ID = 1624467) Radio
AM Radio RP-82; Toshiba Corporation; (ID = 1624468) Radio AM Radio RP-82; Toshiba Corporation; (ID = 1624469) Radio
AM Radio RP-82; Toshiba Corporation; (ID = 1624470) Radio
Use red slider bar for more.
AM Radio RP-82; Toshiba Corporation; (ID = 1624464) Radio
Toshiba Corporation;: AM Radio RP-82 [Radio] ID = 1624464 668x919
Select picture or schematic to display from thumbnails on the right and click for download.
For model AM Radio RP-82, Toshiba Corporation; Tokyo:
Source: ebay.com, dejl1myt, #111292282340

Country:  Japan
Manufacturer / Brand:  Toshiba Corporation; Tokyo
alternative name

Shibaura Engineering Works
Brand
Tokyo Shibaura
Year: 1979 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6:
Main principle Super-Heterodyne (Super in general)
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / AA: 2 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 0.2 W (max.)
from Radiomuseum.org Model: AM Radio RP-82 - Toshiba Corporation; Tokyo
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 64 x 109 x 33 mm / 2.5 x 4.3 x 1.3 inch
Notes

Made in Taiwan.

Model page created by Daniel Rosha. See "Data change" for further contributors.
