• Country
• Japan

• Manufacturer / Brand
• Toshiba Corporation; Tokyo

• Year
• 1985

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 210999

• • alternative name: Shibaura Engineering Works
  • Brand: Tokyo Shibaura

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 450/10700 kHz

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line / Batteries (any type) / 220; 240; 6 x 1,5 Volt

• Loudspeaker
• 4 Loudspeakers

• Power out
• 4.8 W (max.)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: AM/FM Stereo Radio Cassette Recorder RT-6035 - Toshiba Corporation; Tokyo

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 440 x 233 x 103 mm / 17.3 x 9.2 x 4.1 inch

• Notes

• Toshiba Portable AM-FM Stereo Radio Cassette Recorder Model RT-6035.
  Suffix: S-TA, TC, K-AY
  Tuning Ranges: MW 526,5-1606,5 kHz, LW 145-270kHz, SW 5,9-15,4MHz, FM 88-108MHz
  2x 2,4 Watts Power Output, 10%
  Four-Track, two-channel stereophonic, 60 - 10000 Hz
  Speakers: 2x 120mm, 2x 15mm piezo-electric type
  Power Supply:
  TA, TC - AC 120V 60Hz - Power Consumption 10 Watts
  AY - AC 240V 50Hz - Power Consumption 13 Watts
  DC 9V - (6x 1,5V Size "D")
  Carrying Handle, Telescopic antenna.

• Net weight (2.2 lb = 1 kg)
• 2.6 kg / 5 lb 11.6 oz (5.727 lb)

• Source of data
• - - Manufacturers Literature

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
