For model 2013, Canadian Marconi Co. Ltd. (CMC, Esterline), Marconi's Wireless; Montreal, QC

Country:  Canada
Manufacturer / Brand:  Canadian Marconi Co. Ltd. (CMC, Esterline), Marconi's Wireless; Montreal, QC
alternative name

CMC Canada || Marconi, Canada
Year: 1963 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 8: 2SA93 2SA92 2SA49 2SA53 2SB54 2SB54 2SB56 2SB56
Main principle Superheterodyne (common); ZF/IF 455 kHz; 3 AF stage(s)
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Dry Batteries / 4 x 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: 2013 - Canadian Marconi Co. Ltd. CMC,
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Notes

The Canadian Marconi model 2013 is a portable 8-transistor radio. Covers standard broadcast and 4-12 MHz shortwave.

Almost identical to Toshiba 8M-210S. The Canadian Marconi Company (CMC), thanks to an agreement stipulated in 1954 with the Emerson Radio Export Corporation of New York, acquired the right to use the Emerson licenses to produce and to sell in Canada receivers with the brand Emerson. I didn't find trace of any agreement between CMC and Toshiba probably because Marconi/Toshiba sets were produced directly in Japan.

Mentioned in Marconi Transistor Radios (see Aldo Andreani's website).
Literature/Schematics (1) Antique Radio Magazine n.54, April 2003, page 56. Written in Italian and English.
Literature/Schematics (2) Radio College of Canada (RCC) (1963 Supplement 62)

Model page created by Aldo Andreani. See "Data change" for further contributors.
