For model RP-2056, Toshiba Corporation; Tokyo:
Das Bild ist aus der Serviceanleitung des Herstellers.

Country:  Japan
Manufacturer / Brand:  Toshiba Corporation; Tokyo
alternative name

Shibaura Engineering Works
Brand
Tokyo Shibaura
Year: 1986 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10: 2SA1048 2SA1182 2SK184 2SC2458 2SC2458 RN1211 2SC2668 2SC2458 RN1211 2SA1048 TA7358 TA7787 TD6133 TC9183 TA7373 TA7688
Main principle Superheterodyne (common); ZF/IF 450/10700 kHz
Tuned circuits 3 AM circuit(s)     5 FM circuit(s)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Dry Batteries / 2 x 1,5 Volt
Loudspeaker - only for Earphone!
Power out 0.03 W (max.)
from Radiomuseum.org Model: RP-2056 - Toshiba Corporation; Tokyo
Material Plastics (no bakelite or catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 55.5 x 95.5 x 13.5 mm / 2.2 x 3.8 x 0.5 inch
Notes

Das Gerät ist für MW- und FM-Stereo-Empfang über Köpfhörer ausgelegt. Das Kopfhörerkabel dient als Antenne für FM), für MW ist eine Ferritantenne eingebaut. Der NF-Verstärker gibt 2 x 30mW ab. Für AM und FM gibt jeweils 1 Piezo-ZF-Filter. 5 Sender können gespeichert werden.



Net weight (2.2 lb = 1 kg) 0.030 kg / 0 lb 1.1 oz (0.066 lb)

Model page created by Karl-Heinz Entrich. See "Data change" for further contributors.
