For model RP-33, Toshiba Corporation; Tokyo:
Aus der Serviceanleitung des Herstellers.

Country:  Japan
Manufacturer / Brand:  Toshiba Corporation; Tokyo
alternative name

Shibaura Engineering Works
Brand
Tokyo Shibaura
Year: 1985 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 4: 2SC2668 2SK161 2SC2458 2SC2458 TA7371 TA7765 TA7766 BA5152F
Main principle Superheterodyne (common); ZF/IF 455/10700 kHz
Tuned circuits 4 AM circuit(s)     5 FM circuit(s)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Dry Batteries / 1,5 Volt
Loudspeaker - only for Earphone!
Power out 0.01 W (max.)
from Radiomuseum.org Model: RP-33 - Toshiba Corporation; Tokyo
Material Plastics (no bakelite or catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 40 x 70 x 13 mm / 1.6 x 2.8 x 0.5 inch
Notes

Dieses Gerät ermöglicht FM-Stereoempfang wobei das Kopfhörerkabel als Antenne dient. Es ist je ein keramischen ZF-Filter für AM und FM eingebaut. Der Empfang ist nur über Kopfhörer möglich. Leistung je Kanal 10 mW.

Net weight (2.2 lb = 1 kg) 0.045 kg / 0 lb 1.6 oz (0.099 lb)

Model page created by Karl-Heinz Entrich. See "Data change" for further contributors.
