SM-3200

• Country
• Japan

• Manufacturer / Brand
• Toshiba Corporation; Tokyo

• Year
• 1975

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 176702

• • alternative name: Shibaura Engineering Works
  • Brand: Tokyo Shibaura

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Details
• Record Player + Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 110-240 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 24 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: SM-3200 - Toshiba Corporation; Tokyo

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 630 x 178 x 400 mm / 24.8 x 7 x 15.7 inch

• Notes
• Stereo-Kompaktanlage. Radio, Plattenspieler und Kassettenrecorder in einer Anlage.
  Plattenspieler: Riemenantrieb, automatische Endabschaltung und Tonarmlift.
  Kassettenrecorder mit DNL-Schaltung zur Rauschunterdrückung.
  Empfangsbereiche: LW 150...350 kHz; MW 525...1605 kHz; UKW 88...108 MHz. Ausgangsleistung 12 Watt/Kanal. Plattenspieler Motor: 4 poliger Synchronmotor. Tonabnehmer-System: Keramik. Kassetten-Recorder: 2 Spuren-stereo.
