• Year
  • 1938/1939
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 95937

 Technical Specifications

  • Wave bands
  • - without
  • Power type and voltage
  • Dry Batteries / 1.5 & 22.5 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Volt-Ohm-Milliammeter 1200E - Triplett Electrical Instrument
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 8 x 6.5 x 4.5 inch / 203 x 165 x 114 mm
  • Notes
  • Volt-Ohm-Milliammeter 1200E has two instruments AC and DC.

    DC Volts: 10 - 50 - 250 - 500 - 1000 @ 25 kΩ/V
    DC µA: 0 to 50
    DC mA: 1 - 10 - 50 - 250
    Ohms: 1 kΩ - 40 kΩ - 4 MΩ - 40 MΩ
    AC Volts: 10 - 50 - 250 - 500 - 1000

  • Price in first year of sale
  • 47.00 $
  • Literature/Schematics (1)
  • 1938 Radolek Catalog
  • Author
  • Model page created by Vitor Oliveira. See "Data change" for further contributors.
