Tube Analyzer 3444-A
Triplett Electrical Instrument Co.; Bluffton (OH)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Triplett Electrical Instrument Co.; Bluffton (OH)
- Year
- 1960 ??
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 244172
aus ebay, #140863865282, Verkäufer sboochc
aus ebay, #121822399518, Verkäufer jdmsales
aus ebay, #121822399518, Verkäufer jdmsales
aus ebay, #121822399518, Verkäufer jdmsales
aus ebay, #121822399518, Verkäufer jdmsales
aus ebay, #121822399518, Verkäufer jdmsales
aus ebay, #121822399518, Verkäufer jdmsales
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 6
- Semiconductors
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 105-127 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: Tube Analyzer 3444-A - Triplett Electrical Instrument
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 15.19 x 7.75 x 18.19 inch / 386 x 197 x 462 mm
- Notes
-
Gm tube tester, with plate current up to 150 ma @ 250 volts.
- Net weight (2.2 lb = 1 kg)
- 25 lb (25 lb 0 oz) / 11.350 kg
- Author
- Model page created by Gottfried Silberhorn. See "Data change" for further contributors.
