FM500 A50200 with switch
Turner Co. (The); Cedar Rapids (IA)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Turner Co. (The); Cedar Rapids (IA)
- Year
- 1970 ??
- Category
- Microphone or Pick-up element
- Radiomuseum.org ID
- 290610
-
- Brand: Colortone
Turner Catalogue Microphone 1970 - Page 4
- Wave bands
- - without
- Material
- Metal case
- from Radiomuseum.org
- Model: FM500 [A50200 with switch] - Turner Co. The; Cedar Rapids
- Notes
-
Turner Cardioid Dynamic Microphone FM500 Series Model A50200 Fixed Mount with Switch.
Frequency Response 40 - 15000Hz
Discrimination: Typically 20 - 25 dB
Impedance 150 ohms, -57dB output level
Amphenol PC3F 3-pin Connector
Permanently mounted on a coupler assembly
Case:
Die-cast zinc alloy, satin chrome finish
See also:
Turner FM500 Series Model A50201 Fixed Mount without Switch
- Price in first year of sale
- 98.00 USD
- Mentioned in
- -- Original prospect or advert (Turner Catalogue 1970 - Page 4 & 5)
- Author
- Model page created by Franz Scharner. See "Data change" for further contributors.
