UBI 2
Ubisound (Marke)
- Country
- Germany
- Manufacturer / Brand
- Ubisound (Marke)
- Year
- 1980 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 161888
- Number of Transistors
- 2
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- FM Broadcast Band Only
- Power type and voltage
- Alternating Current supply (AC) / 230 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: UBI 2 - Ubisound Marke
- Shape
- Design Radio or Novelty / Gadget - fancy or unusual shape.
- Dimensions (WHD)
- 100 x 100 x 80 mm / 3.9 x 3.9 x 3.1 inch
- Notes
- "Radiosound aus der Steckdose". Nur FM. 16-DIP-LIN-IC-TDA1083 (AM-V, AM/FM-ZF+NF >0,3 Watt/ 5,5Volt/ 8 Ohm); 4 Dioden; Sicherung T250V/500mA
- Net weight (2.2 lb = 1 kg)
- 0.170 kg / 0 lb 6 oz (0.374 lb)
- Author
- Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
