Röhrenvoltmeter RV 4402-315
Ultrakust-Gerätebau O. Raudszus; Ruhmannsfelden
- Country
- Germany
- Manufacturer / Brand
- Ultrakust-Gerätebau O. Raudszus; Ruhmannsfelden
- Year
- 1951 ??
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 303599
- Number of Tubes
- 1
- Valves / Tubes
- VT-90
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Wooden case
- from Radiomuseum.org
- Model: Röhrenvoltmeter RV 4402-315 - Ultrakust-Gerätebau O.
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 270 x 220 x 170 mm / 10.6 x 8.7 x 6.7 inch
- Notes
-
Messbereiche:
U~ 5 V bis 500 V
U= 0,5 V bis 5000 V
I~ 50 mA bis 500 mA
I= 0,1 mA bis 5000 mAFrontblende aus Metall, Gehäuse aus Holz, gegebenfals ein Nachfolgemodell des Röhrenvoltmeters RV3402-002
- Net weight (2.2 lb = 1 kg)
- 4.6 kg / 10 lb 2.1 oz (10.132 lb)
- Author
- Model page created by Karlheinz Fischer. See "Data change" for further contributors.
