• Country
• Germany

• Manufacturer / Brand
• Ultron-Elektronik GmbH; München

• Year
• 1965 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 230224

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• Dry Batteries / AA: 1 x 1,5 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Bakelite or Plastics (type unknown)

• from Radiomuseum.org
• Model: Vielfach-Messinstrument UM-201B - Ultron-Elektronik GmbH;

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 83 x 114 x 29 mm / 3.3 x 4.5 x 1.1 inch

• Notes

• Messbereiche:

  • VAC: 10/50/100/500/1000 V,
  • VDC: 5/25/50/250/500/2500 V,
  • DCA: 50 µA/2,5/250 mA.
  • Widerstandsmessbereiche: ×10 und ×1 k (ca. 5 Ohm - 1 MOhm).

  Innenwiderstand in den DC-Bereichen 20 kOhm/V, in den AC-Bereichen 10 kOhm/V.

  Siehe auch Sansei 200H



• Net weight (2.2 lb = 1 kg)
• 0.270 kg / 0 lb 9.5 oz (0.595 lb)

• Author
• Model page created by Jörg Holtzapfel. See "Data change" for further contributors.
