Convair UHF-Konverter

Convair UHF-Konverter ; Ultron-Elektronik (ID = 902075) Converter

Convair UHF-Konverter ; Ultron-Elektronik (ID = 1516731) Converter

Convair UHF-Konverter ; Ultron-Elektronik (ID = 1516732) Converter

Convair UHF-Konverter ; Ultron-Elektronik (ID = 1516733) Converter
Convair UHF-Konverter ; Ultron-Elektronik (ID = 121181) Converter Convair UHF-Konverter ; Ultron-Elektronik (ID = 121182) Converter
Convair UHF-Konverter ; Ultron-Elektronik (ID = 422035) Converter Convair UHF-Konverter ; Ultron-Elektronik (ID = 422036) Converter
Use red slider bar for more.
Convair UHF-Konverter ; Ultron-Elektronik (ID = 121181) Converter
Ultron-Elektronik: Convair UHF-Konverter [Converter] ID = 121181 765x402
Select picture or schematic to display from thumbnails on the right and click for download.
For model Convair UHF-Konverter, Ultron-Elektronik GmbH; München

Country:  Germany
Manufacturer / Brand:  Ultron-Elektronik GmbH; München
Year: 1968 ?? Category: Pre-stage (adaptor for SW/FM/VHF/UHF incl. built-in), Frequency converter
Semiconductors (the count is only for transistors) 2: unknown_tr
Main principle RF Converter/Adapter (not voltage converter)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 110; 160; 220 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Convair UHF-Konverter - Ultron-Elektronik GmbH;
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, with any shape - general.
Notes

UHF auf VHF. FS-Stromversorgung über eingebaute Steckdose möglich.

Bestückung: 2x UHF-Germanium-Mesa-Transistoren.
[Sehr wahrscheinlich wurden die Typen AF139 oder AF239 verwendet]

Net weight (2.2 lb = 1 kg) 1.8 kg / 3 lb 15.4 oz (3.965 lb)
Source of data -- Original-techn. papers.

Model page created by Robert Latzel. See "Data change" for further contributors.



All listed radios etc. from Ultron-Elektronik GmbH; München
Here you find 46 models, 45 with images and 12 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
