UFT435

UFT435; Robotron- (ID = 1279825) Commercial TRX UFT435; Robotron- (ID = 1264381) Commercial TRX
UFT435; Robotron- (ID = 1264382) Commercial TRX UFT435; Robotron- (ID = 1279826) Commercial TRX
UFT435; Robotron- (ID = 1461183) Commercial TRX UFT435; Robotron- (ID = 1461380) Commercial TRX
Use red slider bar for more.
UFT435; Robotron- (ID = 1279825) Commercial TRX
Robotron-: UFT435 [Commercial TRX] ID = 1279825 535x911
Select picture or schematic to display from thumbnails on the right and click for download.
For model UFT435, Robotron-Messelektronik 'Otto Schön' Dresden, VEB; Dresden, (Ostd.)

Country:  Germany
Manufacturer / Brand:  Robotron-Messelektronik 'Otto Schön' Dresden, VEB; Dresden, (Ostd.)
Year: 1980 Category: Commercial Transmitter & Receiver (TRX not Amateur)
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Transceiver
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Batteries / addl. power jack / 12; 24/ ? Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: UFT435 - Robotron-Messelektronik 'Otto
Material Metal case
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 220 x 105 x 330 mm / 8.7 x 4.1 x 13 inch
Notes

UFT435 für die Luftstreitkräfte der NVA;
Frequenzbereich: 45.6 ... 47.075 MHz,
Wechselsprechen auf einer Reichweite von 5-30 km,
60 Kanäle bei einem Kanalabstand von 25 kHz,
HF Leistung: 600 mW,
NF Bereich: 300 - 4000 Hz,
12, 24 & ~220 V Netzbetrieb mit externem Zubehör.

Das zugehörige Ladegerät LGT7 kann 4 Nickel-Kadmium-Sammler (12 V, 3 Ah) gleichzeitig laden, Ladezeit einzeln einstellbar, max. Ladezeit 17 Stunden.

Net weight (2.2 lb = 1 kg) 6.1 kg / 13 lb 7 oz (13.436 lb)

Model page created by a member from A. See "Data change" for further contributors.



All listed radios etc. from Robotron-Messelektronik 'Otto Schön' Dresden, VEB; Dresden, (Ostd.)
Here you find 33 models, 25 with images and 11 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
