108 Table
Use red slider bar for more.
United Air Cleaner: 108 [Radio] ID = 1520209 933x1172
Select picture or schematic to display from thumbnails on the right and click for download.
For model 108 Table, United Air Cleaner Corp. - see also Sentinel:
Image courtesy of Mark V. Stein for Radiomuseum.org use only. From Machine Age to Jet Age, Volume 2.
|
|
Brand
|
Sentinel
|
Year:
1931 ?
|
Category: Broadcast Receiver - or past WW2 Tuner |
Valves / Tubes |
7:
|
schematic requested |
Main principle |
Superheterodyne (common)
|
Wave bands |
Broadcast only (MW). |
Details |
|
Power type and voltage |
Alternating Current supply (AC) |
Loudspeaker |
Electro Magnetic Dynamic LS (moving-coil with field excitation coil) |
Power out |
|
from Radiomuseum.org |
Model: 108 [Table] - United Air Cleaner Corp. - see |
Material |
Wooden case |
Shape |
Tablemodel, Tombstone = decorative upright, not cathedral but can have rounded edges. |
Mentioned in |
Machine Age to Jet Age II (page 248.) |
Literature/Schematics (1) |
Cathedral & Tombstone Radios (page 230.) |
Model page created by Noemi Erb. See "Data change" for further contributors.
All listed radios etc. from United Air Cleaner Corp. - see also Sentinel
Here you find 43 models, 9 with images and 22 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
