Courier 65

Courier 65 ; United Reproducers (ID = 218615) Radio

Courier 65 ; United Reproducers (ID = 447884) Radio
Courier 65 ; United Reproducers (ID = 995595) Radio Courier 65 ; United Reproducers (ID = 995596) Radio
Courier 65 ; United Reproducers (ID = 995597) Radio Courier 65 ; United Reproducers (ID = 995598) Radio
Courier 65 ; United Reproducers (ID = 995599) Radio Courier 65 ; United Reproducers (ID = 1642713) Radio
Use red slider bar for more.
Courier 65 ; United Reproducers (ID = 995595) Radio
United Reproducers: Courier 65 [Radio] ID = 995595 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Courier 65, United Reproducers Corp. (Peerless); Rochester, NY and Springfield, OH

Country:  United States of America (USA)
Manufacturer / Brand:  United Reproducers Corp. (Peerless); Rochester, NY and Springfield, OH
Year: 1929 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 9: 224 224 224 227 227 245 245 280 199
Main principle TRF (Tuned-Radio-Frequency but use of regeneration unknown); 2 AF stage(s); Screengrid 1926-1935
Tuned circuits 4 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Alternating Current supply (AC) / 110; 125 Volt
Loudspeaker Electrostatic Loudspeaker (high bias DC voltage)
Power out
from Radiomuseum.org Model: Courier 65 - United Reproducers Corp.
Material Metal case
Shape Tablemodel, with any shape - general.
Notes

One dial (primary tuning control knob). This model was equipped either with a dynamic speaker or an electrostatic speaker (Kylectron named after its inventor Colin Kyle). The "199" rectifier tube is not used with dynamic speakers.

Note EE: Actually it is wrong to select the electrostatic speaker for this model since it has no speaker and can run any speaker system, but since electrostatic speakers are very seldom - especially at this time - we do list it here.

Price in first year of sale 85.00 $
Collectors' prices
External source of data Ernst Erb
Source of data Radio Collector`s Guide 1921-1932
Circuit diagram reference Rider's Perpetual, Volume 1 = 1931/1934 (for 1919-1931)
Mentioned in The Radio Collector's Directory and Price Guide 1921 - 1965


All listed radios etc. from United Reproducers Corp. (Peerless); Rochester, NY and Springfield, OH
Here you find 21 models, 12 with images and 10 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
