For model 984296 Pontiac, United Motors Service (Delco)

Country:  United States of America (USA)
Manufacturer / Brand:  United Motors Service (Delco)
alternative name

Delco Radio Corp. (Appliance) || Delco-Remy Division, General Motors Corp. || United Motors Service Delco General Motors
Brand
Chieftain || Delco
Year: 1948 ? Category: Car Radio, perhaps also + sound player/recorder
Valves / Tubes 8: 7A7 7Q7 7A7 7B6 7B6 7C5 7C5 0Z4
Main principle Superhet with RF-stage; ZF/IF 260 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / =6 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: 984296 Pontiac - United Motors Service Delco
Material Metal case
Shape Chassis only or for «building in»
Notes vibrator for +B;
6" x 9" PM elliptical speaker.
External source of data Ernst Erb
Circuit diagram reference Rider's Perpetual, Volume 19 = 1949 and before
