Unikit RF Oscillator OK1

Unikit RF Oscillator OK1; University / (ID = 2355519) Equipment

Unikit RF Oscillator OK1; University / (ID = 2616661) Equipment

Unikit RF Oscillator OK1; University / (ID = 2616662) Equipment

Unikit RF Oscillator OK1; University / (ID = 2616663) Equipment

Unikit RF Oscillator OK1; University / (ID = 2616664) Equipment

Unikit RF Oscillator OK1; University / (ID = 2616666) Equipment

Unikit RF Oscillator OK1; University / (ID = 2616667) Equipment

Unikit RF Oscillator OK1; University / (ID = 2616668) Equipment

Unikit RF Oscillator OK1; University / (ID = 2616669) Equipment

Unikit RF Oscillator OK1; University / (ID = 2616670) Equipment
Unikit RF Oscillator OK1; University / (ID = 1599523) Equipment Unikit RF Oscillator OK1; University / (ID = 1599525) Equipment
Unikit RF Oscillator OK1; University / (ID = 2619289) Equipment Unikit RF Oscillator OK1; University / (ID = 2619290) Equipment
Use red slider bar for more.
Unikit RF Oscillator OK1; University / (ID = 1599523) Equipment
University /: Unikit RF Oscillator OK1 [Equipment] ID = 1599523 900x777
Select picture or schematic to display from thumbnails on the right and click for download.
For model Unikit RF Oscillator OK1, University / University Graham Instruments Pty. Ltd., Radio Equipment Pty. Ltd.; Sydney

Country:  Australia
Manufacturer / Brand:  University / University Graham Instruments Pty. Ltd., Radio Equipment Pty. Ltd.; Sydney
Year: 1947 Category: Service- or Lab Equipment
Valves / Tubes 1: 3S4
Tuned circuits 1 AM circuit(s)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Dry Batteries / 2x 1.5 & 67.5 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Unikit RF Oscillator OK1 - University / University Graham
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 155 x 60 x 205 mm / 6.1 x 2.4 x 8.1 inch
Notes

The University Model OK1 RF Oscillator was sold in kit form for £7- or factory constructed for £9- in 1947.

It was powered by two 1.5V “C” cells and a 67.5V 482 battery. It covered the long and medium band from 160 to 1600 kHz. Shortwave was covered from 16 to 45 Metres.

It was manufactured by Radio Equipment Pty Ltd, 5 North York Street Sydney NSW Australia.

Price in first year of sale 9.00 Aus£
Mentioned in The Australasian Radio World, Dec., 1947 back cover.

Model page created by Gary Cowans. See "Data change" for further contributors.
