8-Transistor-Radio Phonograph Deluxe HiFi ; Unknown - CUSTOM (ID = 1903490) Radio
Unknown - CUSTOM: 8-Transistor-Radio Phonograph Deluxe HiFi [Radio] ID = 1903490 1400x912
Select picture or schematic to display from thumbnails on the right and click for download.
For model 8-Transistor-Radio Phonograph Deluxe HiFi, Unknown - CUSTOM BUILT: Japan

Country:  Japan
Manufacturer / Brand:  Unknown - CUSTOM BUILT: Japan
Year: 1963 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 8: 2SA52 2SA53 2SA49 2SB54 2SB54 2SB54 2SB56 2SB56
Main principle Superheterodyne (common)
Wave bands Broadcast only (MW).
Details Rec.Player+Audio.Amp+LS
Power type and voltage Dry Batteries / 2 x 1.5 & 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 cm = 2 inch
Power out
from Radiomuseum.org Model: 8-Transistor-Radio Phonograph Deluxe HiFi - Unknown - CUSTOM BUILT: Japan
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 244 x 55 x 140 mm / 9.6 x 2.2 x 5.5 inch
Notes

Plattenspieler für 33 und 45 UpM mit AM-Empfänger (MW). Getrennte Stromversorgung für Motor (2x R14-Zelle = 3 V) und 9-V-Block für Empfänger. Feinregelung der Drehzahl.

Motor und Drehko mit Kennzeichnung JAPAN.

Die Bezeichnung "HiFi" auf der Verpackung ist irreführend!

Net weight (2.2 lb = 1 kg) 0.850 kg / 1 lb 14 oz (1.872 lb)

Model page created by Wolfgang Eckardt. See "Data change" for further contributors.
