AM/FM Solid State Ravill M-10

AM/FM Solid State Ravill M-10; Unknown - CUSTOM (ID = 2406851) Radio AM/FM Solid State Ravill M-10; Unknown - CUSTOM (ID = 2406850) Radio
AM/FM Solid State Ravill M-10; Unknown - CUSTOM (ID = 2406852) Radio AM/FM Solid State Ravill M-10; Unknown - CUSTOM (ID = 2276678) Radio
AM/FM Solid State Ravill M-10; Unknown - CUSTOM (ID = 2276677) Radio AM/FM Solid State Ravill M-10; Unknown - CUSTOM (ID = 1624374) Radio
AM/FM Solid State Ravill M-10; Unknown - CUSTOM (ID = 1624376) Radio AM/FM Solid State Ravill M-10; Unknown - CUSTOM (ID = 1624377) Radio
AM/FM Solid State Ravill M-10; Unknown - CUSTOM (ID = 1624378) Radio AM/FM Solid State Ravill M-10; Unknown - CUSTOM (ID = 1624379) Radio
Use red slider bar for more.
AM/FM Solid State Ravill M-10; Unknown - CUSTOM (ID = 2406851) Radio
Unknown - CUSTOM: AM/FM Solid State Ravill M-10 [Radio] ID = 2406851 1349x2100
Select picture or schematic to display from thumbnails on the right and click for download.
For model AM/FM Solid State Ravill M-10, Unknown - CUSTOM BUILT: Hong Kong (HK)

Country:  Hong Kong
Manufacturer / Brand:  Unknown - CUSTOM BUILT: Hong Kong (HK)
Year: 1978 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9:
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Dry Batteries / UM-3: 4 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: AM/FM Solid State Ravill M-10 - Unknown - CUSTOM BUILT: Hong
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 82 x 139 x 47 mm / 3.2 x 5.5 x 1.9 inch
Notes

Military form.

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
