Astra Model-1

Astra Model-1 ; Unknown - CUSTOM (ID = 1536452) Radio
Astra Model-1 ; Unknown - CUSTOM (ID = 1535673) Radio Astra Model-1 ; Unknown - CUSTOM (ID = 1535674) Radio
Astra Model-1 ; Unknown - CUSTOM (ID = 1535676) Radio Astra Model-1 ; Unknown - CUSTOM (ID = 1535678) Radio
Astra Model-1 ; Unknown - CUSTOM (ID = 1535680) Radio Astra Model-1 ; Unknown - CUSTOM (ID = 1535682) Radio
Astra Model-1 ; Unknown - CUSTOM (ID = 1535683) Radio Astra Model-1 ; Unknown - CUSTOM (ID = 1535686) Radio
Astra Model-1 ; Unknown - CUSTOM (ID = 1535687) Radio Astra Model-1 ; Unknown - CUSTOM (ID = 1535688) Radio
Use red slider bar for more.
Astra Model-1 ; Unknown - CUSTOM (ID = 1535673) Radio
Unknown - CUSTOM: Astra Model-1 [Radio] ID = 1535673 900x675
Select picture or schematic to display from thumbnails on the right and click for download.
For model Astra Model-1, Unknown - CUSTOM BUILT: Japan

Country:  Japan
Manufacturer / Brand:  Unknown - CUSTOM BUILT: Japan
Year: 1960 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 12BE6 12BA6 12AV6 50C5 35W4
Main principle Super-Heterodyne (Super in general)
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage AC/DC-set / 120 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3.5 inch = 8.9 cm
Power out
from Radiomuseum.org Model: Astra Model-1 - Unknown - CUSTOM BUILT: Japan
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 7 x 4.5 x 4 inch / 178 x 114 x 102 mm
Notes

Made in Japan.

See also the similar model Alco Model-1.

Net weight (2.2 lb = 1 kg) 0.960 kg / 2 lb 1.8 oz (2.115 lb)
Source of data -- Schematic

Model page created by Jean-Pierre Desrochers. See "Data change" for further contributors.
