For model Berlin 8 Transistor Deluxe (Japan 713), Unknown - CUSTOM BUILT: Japan

Country:  Japan
Manufacturer / Brand:  Unknown - CUSTOM BUILT: Japan
Year: 1968 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 8:
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage Batteries / addl. power jack / UM-2: 4× 1,5 / 6 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9 cm = 3.5 inch
Power out 0.5 W (unknown quality)
from Radiomuseum.org Model: Berlin 8 Transistor Deluxe - Unknown - CUSTOM BUILT: Japan
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 224 x 136 x 58 mm / 8.8 x 5.4 x 2.3 inch
Notes

Berlin 8 Transistor Deluxe, 3 Band Hi-Fi; SW: up to ~22 MHz, dial light, signal/batt. meter, silver metal front, telescopic antenna, suitable brown leather case known.

Two, various chassis and scale.

Made in Japan 713

Net weight (2.2 lb = 1 kg) 1.1 kg / 2 lb 6.8 oz (2.423 lb)
Source of data -- Collector info (Sammler)

Model page created by a member from A. See "Data change" for further contributors.
