Davos AM/FM Solid State

Unknown - CUSTOM BUILT: Hong Kong (HK)

  • Year
  • 1979 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 255008

 Technical Specifications

  • Number of Transistors
  • 10
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Power type and voltage
  • Dry Batteries / 6LR61: 9 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7 cm = 2.8 inch
  • Power out
  • 0.3 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Davos AM/FM Solid State - Unknown - CUSTOM BUILT: Hong
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 148 x 92 x 43 mm / 5.8 x 3.6 x 1.7 inch
  • Notes
  • AFC Taschenradio mit schwenkbarer Teleskopantenne und Ohrhöreranschlussbuchse 3,5mm

    Bänder:
    AM: 535 - 1605kHz
    FM:   88 - 108MHz.

    Siehe auch Weltfunk Solid State AM/FM.

  • Net weight (2.2 lb = 1 kg)
  • 0.350 kg / 0 lb 12.3 oz (0.771 lb)
  • Author
  • Model page created by Holger Struthoff. See "Data change" for further contributors.
