• Year
  • 1960 ??
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 191810

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 18
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Alternating Current supply (AC) / 127; 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Енисей Yenisey - Krasnoyarsk Television Plant;
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 450 x 410 x 460 mm / 17.7 x 16.1 x 18.1 inch
  • Net weight (2.2 lb = 1 kg)
  • 24 kg / 52 lb 13.8 oz (52.863 lb)
  • Literature/Schematics (1)
  • G.P. Samojlov, 1965
  • Author
  • Model page created by a member from D. See "Data change" for further contributors.
