• Country
• Germany

• Manufacturer / Brand
• PeakTech GmbH, Heinz-Günther Lau (HGL, H.G.L., Exacta); Ahrensburg

• Year
• 1970 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 214235

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• Dry Batteries / AA: 2 x 1,5 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Bakelite case

• from Radiomuseum.org
• Model: Exacta M-650 - PeakTech GmbH, Heinz-Günther

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 130 x 90 x 35 mm / 5.1 x 3.5 x 1.4 inch

• Notes

• Kleines preiswertes Vielfachinstrument zum Messen von Spannungen, Strömen und Widerständen.

  Siehe auch Herton CT-630

• Source of data
• -- Original-techn. papers.

• Author
• Model page created by Heiko zur Mühlen. See "Data change" for further contributors.
