FM Alarm Clock Radio

Unknown to us - Worldwide

Data

Forum

Pictures

Collections

Country
Worldwide

Manufacturer / Brand
Unknown to us - Worldwide

Year
1990 ??

Category
Broadcast Receiver - or past WW2 Tuner

Radiomuseum.org ID
324152

Schematics

FM Alarm Clock Radio ; Unknown to us - (ID = 2570618) Radio — Unknown to us - FM Alarm Clock Radio (1)

FM Alarm Clock Radio ; Unknown to us - (ID = 2570620) Radio — Unknown to us - FM Alarm Clock Radio (1)

FM Alarm Clock Radio ; Unknown to us - (ID = 2570619) Radio — Unknown to us - FM Alarm Clock Radio (1)

FM Alarm Clock Radio ; Unknown to us - (ID = 2570621) Radio — Unknown to us - FM Alarm Clock Radio (1)

FM Alarm Clock Radio ; Unknown to us - (ID = 2580629) Radio — Unknown to us - FM Alarm Clock Radio (1)

FM Alarm Clock Radio ; Unknown to us - (ID = 2580631) Radio — Unknown to us - FM Alarm Clock Radio (1)

FM Alarm Clock Radio ; Unknown to us - (ID = 2580633) Radio — Unknown to us - FM Alarm Clock Radio (1)

FM Alarm Clock Radio ; Unknown to us - (ID = 2642315) Radio — Unknown to us - FM Alarm Clock Radio (1)

FM Alarm Clock Radio ; Unknown to us - (ID = 2642316) Radio — Unknown to us - FM Alarm Clock Radio (1)

FM Alarm Clock Radio ; Unknown to us - (ID = 2642317) Radio — Unknown to us - FM Alarm Clock Radio (1)

FM Alarm Clock Radio ; Unknown to us - (ID = 2642318) Radio — Unknown to us - FM Alarm Clock Radio (1)

FM Alarm Clock Radio ; Unknown to us - (ID = 2642319) Radio — Unknown to us - FM Alarm Clock Radio (1)

Technical Specifications

Number of Transistors
10

Semiconductors

Main principle
Superheterodyne (common)

Tuned circuits
7 FM circuit(s)

Wave bands
FM Broadcast Band Only

Details
Radio with other functions

Power type and voltage
Batteries / addl. power jack / 4,5 / AA: 3 x 1.5 Volt

Loudspeaker
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.5 cm = 2.2 inch

Power out
0.5 W (unknown quality)

Material
Plastics (no bakelite or catalin)

from Radiomuseum.org
Model: FM Alarm Clock Radio - Unknown to us - Worldwide

Shape
Very small Portable or Pocket-Set (Handheld) < 8 inch.

Dimensions (WHD)
140 x 70 x 35 mm / 5.5 x 2.8 x 1.4 inch

Notes
FM Taschenradio mit Uhr und Weckfunktion.

FM pocket radio with clock and alarm function.

Author
Model page created by Uwe Friedl. See "Data change" for further contributors.
