For model International DO-8, Unknown Worldwide

Country:  Worldwide
Manufacturer / Brand:  Unknown Worldwide
Year: 1982 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 8:
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Dry Batteries / 3 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.5 cm = 2.2 inch
Power out 0.1 W (unknown quality)
from Radiomuseum.org Model: International DO-8 - Unknown Worldwide
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 70 x 142 x 30 mm / 2.8 x 5.6 x 1.2 inch
Notes AM/FM Portable mit Gürtelspange, LED-Betriebsanzeige, Kopfhöreranschluß über 3,5 mm Klinkenbuchse, Teleskopantenne 48 cm, Ferritantenne 5,5 cm
Net weight (2.2 lb = 1 kg) 0.240 kg / 0 lb 8.5 oz (0.529 lb)

Model page created by Peter Roggenhofer † 25.4.18. See "Data change" for further contributors.
