Kapitan HIFI Deluxe 8 Transistor TR-1500

Kapitan HIFI Deluxe 8 Transistor TR-1500; Dreamland (ID = 692093) Radio Kapitan HIFI Deluxe 8 Transistor TR-1500; Dreamland (ID = 692091) Radio
Kapitan HIFI Deluxe 8 Transistor TR-1500; Dreamland (ID = 692092) Radio Kapitan HIFI Deluxe 8 Transistor TR-1500; Dreamland (ID = 1008298) Radio
Kapitan HIFI Deluxe 8 Transistor TR-1500; Dreamland (ID = 1008300) Radio Kapitan HIFI Deluxe 8 Transistor TR-1500; Dreamland (ID = 1008302) Radio
Kapitan HIFI Deluxe 8 Transistor TR-1500; Dreamland (ID = 1008304) Radio Kapitan HIFI Deluxe 8 Transistor TR-1500; Dreamland (ID = 1015069) Radio
Kapitan HIFI Deluxe 8 Transistor TR-1500; Dreamland (ID = 1015070) Radio Kapitan HIFI Deluxe 8 Transistor TR-1500; Dreamland (ID = 1015071) Radio
Use red slider bar for more.
Kapitan HIFI Deluxe 8 Transistor TR-1500; Dreamland (ID = 692093) Radio
Dreamland: Kapitan HIFI Deluxe 8 Transistor TR-1500 [Radio] ID = 692093 790x498
Select picture or schematic to display from thumbnails on the right and click for download.
For model Kapitan HIFI Deluxe 8 Transistor TR-1500, Dreamland Electronics Manufactory; Hong Kong

Country:  Hong Kong
Manufacturer / Brand:  Dreamland Electronics Manufactory; Hong Kong
Year: 1966 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6:
Main principle Superheterodyne (common)
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7 cm = 2.8 inch
Power out 0.1 W (unknown quality)
from Radiomuseum.org Model: Kapitan HIFI Deluxe 8 Transistor TR-1500 - Dreamland Electronics
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 137 x 80 x 38 mm / 5.4 x 3.1 x 1.5 inch
Notes MW-Portable mit Kopfhöreranschluß über 3,5 mm Klinkenbuchse. Ferritantenne 9 cm. Es steht zwar "8-Transistor" auf dem Modell,- es sind jedoch nur 6 eingebaut... Different body colors known.
Net weight (2.2 lb = 1 kg) 0.270 kg / 0 lb 9.5 oz (0.595 lb)

Model page created by Peter Roggenhofer † 25.4.18. See "Data change" for further contributors.



All listed radios etc. from Dreamland Electronics Manufactory; Hong Kong
Here you find 47 models, 46 with images and 2 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
