Lautsprecherchassis 0,5GD-31 [0,5ГД-31]
Unknown - CUSTOM BUILT: Soviet Union
- Country
- Soviet Union
- Manufacturer / Brand
- Unknown - CUSTOM BUILT: Soviet Union
- Year
- 1978 ??
- Category
- Loudspeaker, headphone or earphone
- Radiomuseum.org ID
- 284100
![Lautsprecherchassis 0,5GD-31 [0,5ГД-31]; Unknown - CUSTOM (ID = 2022514) Speaker-P](/images/radio/unknown_custom_built/lautsprecherchassis_0_5gd_31_0_5_31_2022514.jpg)
![Lautsprecherchassis 0,5GD-31 [0,5ГД-31]; Unknown - CUSTOM (ID = 2022515) Speaker-P](/images/radio/unknown_custom_built/lautsprecherchassis_0_5gd_31_0_5_31_2022515.jpg)
![Lautsprecherchassis 0,5GD-31 [0,5ГД-31]; Unknown - CUSTOM (ID = 2022517) Speaker-P](/images/radio/unknown_custom_built/lautsprecherchassis_0_5gd_31_0_5_31_2022517.jpg)
- Wave bands
- - without
- Power type and voltage
- No Power needed
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Metal case
- from Radiomuseum.org
- Model: Lautsprecherchassis 0,5GD-31 [0,5ГД-31] - Unknown - CUSTOM BUILT: Soviet
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 122 x 80 x 46 mm / 4.8 x 3.1 x 1.8 inch
- Notes
-
Ovales Breitband-Lautsprecherchassis; Impedanz: 16 Ω; Korb: offen, Stahlblech mit 4 Befestigungslöchern.
- Net weight (2.2 lb = 1 kg)
- 0.184 kg / 0 lb 6.5 oz (0.405 lb)
- Author
- Model page created by Michael Mischke. See "Data change" for further contributors.
