Mamiye 15

Mamiye 15 ; Unknown - CUSTOM (ID = 1793896) Radio Mamiye 15 ; Unknown - CUSTOM (ID = 1793895) Radio
Mamiye 15 ; Unknown - CUSTOM (ID = 1793898) Radio Mamiye 15 ; Unknown - CUSTOM (ID = 1796176) Radio
Mamiye 15 ; Unknown - CUSTOM (ID = 1796177) Radio
Use red slider bar for more.
Mamiye 15 ; Unknown - CUSTOM (ID = 1793896) Radio
Unknown - CUSTOM: Mamiye 15 [Radio] ID = 1793896 1400x1038
Select picture or schematic to display from thumbnails on the right and click for download.
For model Mamiye 15, Unknown - CUSTOM BUILT: South Korea (ROK)

Country:  South Korea
Manufacturer / Brand:  Unknown - CUSTOM BUILT: South Korea (ROK)
Year: 1967 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: 2SC469 2SC185 2SC183 2SC183 2SC183 2SB185 2SB185 2SB56 2SB56
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Dry Batteries
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Mamiye 15 - Unknown - CUSTOM BUILT: South
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 80 x 130 x 40 mm / 3.1 x 5.1 x 1.6 inch

Model page created by Michael Gnaedig-Fischer. See "Data change" for further contributors.
