Micro-Sonic

Unknown - CUSTOM BUILT: Hong Kong (HK)

Data
Forum
Pictures
Collections

  • Year
  • 1965 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 91554

 Technical Specifications

  • Number of Transistors
  • 7
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 2 × 1,2 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4.5 cm = 1.8 inch
  • Power out
  • 0.04 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Micro-Sonic - Unknown - CUSTOM BUILT: Hong
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 60 x 70 x 30 mm / 2.4 x 2.8 x 1.2 inch
  • Notes

  • Dieses Gerät ist identisch mit dem Radioempfänger Kosmos M, der in der Sowjetunion im Sarapul-Radiofabrik Г.К. Орджоникидзе hergestellt wurde.

    В комплекте зарядное устройство для двух никель-кадмиевых аккумуляторов, кожаный чехол, ремешок для переноски. Разные цвета. Чувствительность 5 мВ/м.

  • Net weight (2.2 lb = 1 kg)
  • 0.1 kg / 0 lb 3.5 oz (0.22 lb)
  • Author
  • Model page created by Hannes Wurnitsch. See "Data change" for further contributors.
