Neva (Нева)

Neva ; Leningrad NOVATOR (ID = 667103) Radio

Neva ; Leningrad NOVATOR (ID = 667104) Radio
Neva ; Leningrad NOVATOR (ID = 415996) Radio Neva ; Leningrad NOVATOR (ID = 415997) Radio
Neva ; Leningrad NOVATOR (ID = 415998) Radio Neva ; Leningrad NOVATOR (ID = 415999) Radio
Use red slider bar for more.
Neva ; Leningrad NOVATOR (ID = 415996) Radio
Leningrad NOVATOR: Neva [Radio] ID = 415996 467x540
Select picture or schematic to display from thumbnails on the right and click for download.
For model Neva (Нева), Leningrad NOVATOR Works:
Thanks for Valery Charcenko, Russia

Country:  Soviet Union
Manufacturer / Brand:  Leningrad NOVATOR Works
Year: 1960/1961 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: П402 П402 П402 П13 П13 П13
Main principle Super-Heterodyne (Super in general); ZF/IF 465 kHz
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 8.4 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 0.1 W (unknown quality)
from Radiomuseum.org Model: Neva - Leningrad NOVATOR Works
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 126 x 77 x 36 mm / 5 x 3 x 1.4 inch
Notes Gemäss "radio und fernsehen" 19-1961, Seiten 616/617, dient dem Modell "Newa" eine Akkumulatorenbatterie von 8,4 V mit einer Betriebsdauer von 12 Stunden als Speisequelle. Ausgestattet ist das Gerät mit einem Lautsprecher, der einen permanenten Magneten besitzt. Die Ausgangsleistung beträgt 90 mW. Ferritantenne und gedruckte Schaltung.
Net weight (2.2 lb = 1 kg) 0.3 kg / 0 lb 10.6 oz (0.661 lb)
Source of data -- Schematic
Literature/Schematics (1) Radio und Fernsehen (DDR) (Nr. 19-1961, Seiten 616,617)

Model page created by Iven Müller. See "Data change" for further contributors.



All listed radios etc. from Leningrad NOVATOR Works
Here you find 27 models, 26 with images and 17 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
