Pal Sonic AM/FM Jogger LK-3000

Unknown to us - Worldwide

Data
Forum
Pictures
Collections

  • Year
  • 2000 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 304014

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Power type and voltage
  • Dry Batteries / 2 x 1,5 Volt
  • Loudspeaker
  • 2 Loudspeakers / Ø 3.5 cm = 1.4 inch
  • Power out
  • 0.2 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Pal Sonic AM/FM Jogger LK-3000 - Unknown to us - Worldwide
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 195 x 200 x 60 mm / 7.7 x 7.9 x 2.4 inch
  • Notes

  • controllo volume - antenna esterna - estremità pieghevoli - led rosso accensione - commutatore AM/FM.

  • Net weight (2.2 lb = 1 kg)
  • 0.550 kg / 1 lb 3.4 oz (1.211 lb)
  • Author
  • Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
