9" Field Coil Speaker 6-0151
RCA (RCA Victor Co. Inc.); New York (NY)
- Country
- United States of America (USA)
- Manufacturer / Brand
- RCA (RCA Victor Co. Inc.); New York (NY)
- Year
- 1929/1930
- Category
- Loudspeaker, headphone or earphone
- Radiomuseum.org ID
- 280092
-
- alternative name: RCA Manufacturing || Victor Talking Machine
- Wave bands
- - without
- Power type and voltage
- Powered by external power supply or a main unit. / 115 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 9 inch = 22.9 cm
- Material
- Metal case
- from Radiomuseum.org
- Model: 9" Field Coil Speaker 6-0151 - RCA RCA Victor Co. Inc.; New
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 9 x 9 x 7 inch / 229 x 229 x 178 mm
- Notes
-
Employed in RCA Victor Electrolas ( e.g. RE-45 )
- Net weight (2.2 lb = 1 kg)
- 10 kg / 22 lb 0.4 oz (22.026 lb)
- Author
- Model page created by Michael Gnaedig-Fischer. See "Data change" for further contributors.
